Fast & Powerful Integrity Sheets
Skyline Integrity Edition is the first of its kind to target the need for quick integrity alignment sheets in CAD in an industry with tightening regulations. This tool uses the Skyline engine to provide integrity groups powerful functionality on a smaller budget.
Features
Automated Plan View
Automated Stationing Bands
Automatically inserts North Arrow
Writes to Microsoft Access
Smart Groups create optimized viewport layouts with a click
Insert Points from a csv directly into dwg
Generate Linework from points
Generate sheets left to right, and right to left
Compatible with metric and Imperial units
Stream data from Orbital projects
Compatible with AutoCAD 2015 to 2020
Automatically Update Single Bands or All Bands
View and Manage Data
Utilizes AutoCAD Text Styles
Utilizes AutoCAD Line Styles
Map bands to your border
Easily switch between different borders
Automated Profile Band
Automated Chainage Bands
Automated TOP Bands
Automated NG Bands
Automated DOC Bands
Automated PI Bands
Automated Crossing Bands
Automated PI Table
Includes the ProGen extension to draw and manage multiple profile surface
Dynamic previews help you get settings right the first time
Centralized profile along all the sheets
Export sheets to unique dwg files
Export all sheets to single dwg file
Benefits
Produces unrivaled deliverables with clean, professional output
Increases value of your deliverables
Runs in conjunction with Skyline
Allows for smoother audits with comprehensive data
Enables the user to quickly move from survey to sheet generation
Dramatically increases productivity
Processes changes extremely quickly
Reduces the duplication of effort
Writes all data to a project database for easy management
Enables the user to cut sheets from PODS Spatial data
All data is loadable into PODS and PODS Spatial
